Ball check valve 702
Technical Specifications
-
Nominal diameter DN 40-600 -
Nominal pressure PN 10, PN16 -
Medium temperature -60 °C ... +120 °C -
Types of Valve End Connections Flanged, welded -
Leakage Class «А» -
Warranty Period 12 months -
Mounting Position Horizontally, vertically -
Types of Control Automatic (ball) -
Average Service Life 10 000 cycles -
Guaranteed Service Life Not less than 5000 cycles
Technical Drawings and Dimensions
Product Description
The ball check valve model 702 is designed to ensure unidirectional flow in installations where the following are important:
-
High resistance to contamination and solid particles
-
Maintenance-free operation and reliable performance
-
Long service life even under harsh process conditions
The valve’s design allows for automatic shutoff of the flow using a freely moving ball that shifts due to pressure differences. The absence of complex mechanisms makes this valve extremely durable and easy to operate, even in aggressive or particle-laden environments.
Design features of the model:
-
Intended for industrial installations with water, wastewater, contaminated or chemically aggressive liquids
-
No spring – the ball operates based on pressure differential
-
Self-cleaning ball available (in versions with appropriate surface finish)
-
Low pressure drop thanks to simple flow geometry
-
Easy maintenance – access to internal components without removing the valve from the pipeline (in flanged and bolted versions)
Working media:
-
Water, wastewater, liquids with suspended solids
-
Petroleum products, oils, gasoline
-
Acids and alkalis (depending on material version)
-
Chemically aggressive media (including those with phosphates, sulfur)
-
Liquids containing solids: sand, coal, sludge
Body / ball materials:
🔹 Carbon steels:
ASTM A216 WCB (1.0619)
🔹 Low-alloy steels:
ASTM A352 LCB / LC1 (~P355NL1 / 1.0566)
🔹 Stainless / corrosion-resistant steels:
ASTM A351 CF8 / AISI 304 (1.4308 / 1.4301)
ASTM A351 CF8M / AISI 316 (1.4408 / 1.4401)
ASTM A351 CF3 / AISI 304L (1.4306 / 1.4306)
ASTM A351 CF3M / AISI 316L (1.4409 / 1.4404)
AISI 904L (1.4539)
